60000kg Single Axle Truck Weigh In Motion Scales 90%-97% Accuracy
| Place of Origin | Zhenghou`China |
|---|---|
| Brand Name | Hengliang |
| Certification | ISO |
| Model Number | ZQS-40-SY |
| Minimum Order Quantity | 1 SET |
| Price | USD 20000-35000/SET |
| Packaging Details | Wooden box |
| Delivery Time | 5~7days |
| Payment Terms | T/T |
| Supply Ability | 30 SET/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | High Speed Weight In Motion | Power Voltage | AC 220V 50Hz |
|---|---|---|---|
| Weighing Error | 3%~10% | Speed Range | 0.5~105km/h |
| Single Axle Load | 40T | Maximum Load | 60T (single Axle) |
| Division Value | 50kg | MTBF | ≥20000h |
| Temperature Range | -45~+80℃ | Protection Level | IP68 |
| Highlight | 60000kg Truck Weigh In Motion,weigh in motion scales 97% Accuracy,97% Accuracy Truck Weigh In Motion |
||
Product Description
Max 60000kg Single Axle Dynamic Weighing System For High Speed Weigh In Motion
Product Function
- Detect the total weight, axle weight, number of axles, speed, wheelbase and equivalent axle times of vehicles running at high and low speed (speed: 0.5 ~ 105km / h), and automatically separate the vehicles.
- Detect vehicle license plate.
- Form complete vehicle output information, including vehicle passing time, location, license plate, total vehicle weight, axle weight, axle group weight, axle number, vehicle speed, wheelbase, vehicle model and other indicators.
- Set the overload weight limit according to the requirements of the judgment standard for overloaded vehicles, which can also be adjusted conveniently to automatically judge whether the vehicle is overloaded.
- The data of out of gauge and overloaded vehicles will be automatically uploaded to the data center of the designated management department to provide basis for the later treatment of illegal acts by the management department.
Product Parameters
| Weighing accuracy | 90%~97% |
| Single axle load | 40Ton |
| Max Load | 60Ton |
| Speed | 0.5~105km/h； |
| Speed error | ≤±1km/h |
| Wheelbase error | ≤±100mm |
| Working voltage | AC 220V 50Hz |
| Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
| Maximum number of lanes | 8 lanes |
| Data storage | It can store up to 10000 pieces of vehicle information data |
| data interface | RJ485 |
| work environment | -45℃～80℃,0～95% |
| Confidence | ≥95% |
