ISO Bending Plate High Speed Weigh In Motion System Highway Management
| Place of Origin | Zhenghou`China |
|---|---|
| Brand Name | Hengliang |
| Certification | ISO |
| Model Number | ZQS-40-SY |
| Minimum Order Quantity | 1 SET |
| Price | USD 20000-35000/SET |
| Packaging Details | Wooden box |
| Delivery Time | 5~7days |
| Payment Terms | T/T |
| Supply Ability | 30 SET/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | High Speed Weight In Motion | Power | AC 110~220V |
|---|---|---|---|
| Dynamic Weighing Accuracy | 90%~97% | Speed | 0.5~105km/h |
| Rated Load Of Single Axle | 40T | Maximum Overload Capacity | 60T (single Axle) |
| MTBF | ≥20000h | Temperature Range | -45~+80℃ |
| Highlight | ISO High Speed Weight In Motion,ISO bending plate weigh in motion,weight in motion system Highway Management |
||
Product Description
0.5~105km/H High Speed Weight In Motion System For Highway Management
Product Function
1. Automatic identifying vehicle’s driving direction and meanwhile detecting forward and reverse vehicles
2. Dynamic weighing accuracy:97%；
3. Accurate detect high-speed vehicles’ speed and axle load, wheelbase, vehicle model, pass time and other information;
4. Accurately capture images of high-speed driving vehicle in real-time, and quickly identify the vehicle's license plate number;
5. Accurately matched license plate number with vehicle information;
6. Accurate and real-time display user’s set content;
7. According to the standard that the user set, automatically judge whether vehicles speeding, overweight, and starts the alarm device;
8. Have data storage function, can store up to 10000 vehicle information;
9. Provide lane number, time, license plate, the overweight rate, the number of shaft and other retrieval conditions, convenient user inquiry data;
10. Provide one car, different number of shaft, specified period of time, overweight rate and other kinds of statistical reports.
11. Test high speed (speed: 0.5 ~ 105 km/h) vehicle’s axle load, speed, wheelbase, total weight and can separate automatically;
12. System adaptability is strong, such as terrain slope, corner has been used successfully. In the fog, rain, such bad weather, will not affect the normal operation of system, also does not affect the accuracy of weighing and speed test.
Product Parameters
| Weighing accuracy | 90%~97% |
| Single axle load | 40Ton |
| Max Load | 60Ton |
| Speed | 0.5~105km/h； |
| Speed error | ≤±1km/h |
| Wheelbase error | ≤±100mm |
| Working voltage | AC 220V 50Hz |
| Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
| Maximum number of lanes | 8 lanes |
| Data storage | It can store up to 10000 pieces of vehicle information data |
| data interface | RJ485 |
| work environment | -45℃～80℃,0～95% |
| Confidence | ≥95% |
