IP68 Weigh In Motion Truck Scales AC220V 50Hz WIM Sensor
| Place of Origin | Zhenghou`China |
|---|---|
| Brand Name | Hengliang |
| Certification | ISO |
| Model Number | ZQS-40-SY |
| Minimum Order Quantity | 1 SET |
| Price | USD 20000-35000/SET |
| Packaging Details | Wooden box |
| Delivery Time | 5~7days |
| Payment Terms | T/T |
| Supply Ability | 30 SET/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Weigh In Motion Truck Scale | Voltage | AC 220V |
|---|---|---|---|
| Weighing Accuracy | 90%~97% | Speed Range | 0.5~105km/h |
| Single Axle Load | 40T | Max Single Axle Load | 60T |
| Division Value | 50kg | MTBF | ≥20000h |
| Working Temperature Range | -45~+80℃ | Protection Grade | IP68 |
| Highlight | IP68 Weigh In Motion Truck Scales,AC220V 50Hz WIM Sensor,IP68 Truck WIM Sensor |
||
Product Description
90%~97% High Accuracy Dynamic Weighing System & Truck Scales
Product Function
- After the vehicle passes through the weighing area, carry out control alarm and vehicle early warning prompt to view the early warning details.
- Based on geographic information system, conduct real-time communication with law enforcement personnel and law enforcement vehicles around the location of warning vehicles, and assign vehicle inspection, control, interception and law enforcement tasks to mobile law enforcement terminals nearby.
- It can track, record, feed back and replay law enforcement tasks.
- Receive the text, picture and video information fed back by the on-site law enforcement personnel through the mobile law enforcement terminal, and archive the whole process.
Product Parameters
| Weighing accuracy | 90%~97% |
| Single axle load | 40Ton |
| Max Load | 60Ton |
| Speed | 0.5~105km/h； |
| Speed error | ≤±1km/h |
| Wheelbase error | ≤±100mm |
| Working voltage | AC 220V 50Hz |
| Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
| Maximum number of lanes | 8 lanes |
| Data storage | It can store up to 10000 pieces of vehicle information data |
| data interface | RJ485 |
| work environment | -45℃～80℃,0～95% |
| Confidence | ≥95% |
