Dynamic Quartz Weigh In Motion Wim Single Axle 40T For Highway
| Place of Origin | Zhenghou`China |
|---|---|
| Brand Name | Hengliang |
| Certification | ISO |
| Model Number | ZQS-40-SY |
| Minimum Order Quantity | 1 SET |
| Price | USD 20000-35000/SET |
| Packaging Details | Wooden box |
| Delivery Time | 5~7days |
| Payment Terms | T/T |
| Supply Ability | 30 SET/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Weigh In Motion Truck Scale | Working Power | AC 220V |
|---|---|---|---|
| Weighing Error | 3%~10% | Speed | 0.5~105km/h |
| Single Axle Load | 40T | Max Single Axle Load | 60T |
| Division Value | 50kg | MTBF | ≥20000h |
| Temperature Range | -45~+80℃ | Protection Level | IP68 |
| Highlight | Dynamic Quartz Weigh In Motion Wim,truck axle scales 40T,Highway 40T Weigh In Motion Wim |
||
Product Description
Piezoelectric Dynamic Axle Weighing System & In Motion Axle Scale
Product Function
- Realize intelligent analysis, according the condition of time period, where the car passed to analyzed, and display in the form of a chart.
- Provide function of system network connection test, can dynamic rendering system topology structure, real-time test connection status of each node in the network.
- Provide user management, data backup and restore data, and other functions for advanced permissions users.
- High-speed preview information management software provides management functions for multiple remote testing site, for testing station peripherals with state detection function.
Product Parameters
| Weighing accuracy | 90%~97% |
| Single axle load | 40Ton |
| Max Load | 60Ton |
| Speed | 0.5~105km/h； |
| Speed error | ≤±1km/h |
| Wheelbase error | ≤±100mm |
| Working voltage | AC 220V 50Hz |
| Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
| Maximum number of lanes | 8 lanes |
| Data storage | It can store up to 10000 pieces of vehicle information data |
| data interface | RJ485 |
| work environment | -45℃～80℃,0～95% |
| Confidence | ≥95% |
