0.5-105km/H In Motion Axle Scale AC220V 50Hz Weigh In Motion Wim

Name: 0.5-105km/H In Motion Axle Scale AC220V 50Hz Weigh In Motion Wim
Brand: Zhengzhou Hengliang Tech Co., Ltd.
SKU: ZQS-40-SY
Price: 27,500.00 USD
Availability: InStock

Product Details

Place of Origin: Zhenghou`China

Brand Name: Hengliang

Certification: ISO

Model Number: ZQS-40-SY

Payment & Shipping Terms

Minimum Order Quantity: 1 SET

Price: USD 20000-35000/SET

Packaging Details: Wooden box

Delivery Time: 5~7days

Payment Terms: T/T

Supply Ability: 30 SET/Month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                    105km/h In Motion Axle Scale, AC220V 50Hz Weigh In Motion Wim, In Motion Axle Scale AC220V 50Hz


Type:	In Motion Axle Scale	Working Voltage:	AC 110~220V
Weighing Accuracy:	90%~97%	Speed Rate:	0.5~105km/h
Single Axle Load:	40T	Max Load:	60T (single Axle)
Division Value:	50kg	MTBF:	≥20000h
Temperature Range:	-45~+80℃	Protection Level:	IP68

Type:	In Motion Axle Scale
Working Voltage:	AC 110~220V
Weighing Accuracy:	90%~97%
Speed Rate:	0.5~105km/h
Single Axle Load:	40T
Max Load:	60T (single Axle)
Division Value:	50kg
MTBF:	≥20000h
Temperature Range:	-45~+80℃
Protection Level:	IP68

Product Description

High Precision Dynamic In Motion Axle Scale System & 40T Single Axle

Product Function

On the main roads, fully automatic detection equipment for high-speed weighing of vehicles is installed. On the basis of not affecting normal traffic, the axle load and wheelbase of vehicles can be detected to judge the overloaded vehicle. Through the information network, the information of overloaded vehicles can be transmitted to the monitoring center, overrun detection station and mobile detection station in real time, so as to achieve comprehensive control over the overweight vehicles entering the urban area.

Product Parameters

Weighing accuracy	90%~97%
Single axle load	40Ton
Max Load	60Ton
Speed	0.5~105km/h；
Speed error	≤±1km/h
Wheelbase error	≤±100mm
Working voltage	AC 220V 50Hz
Output information	Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time
Maximum number of lanes	8 lanes
Data storage	It can store up to 10000 pieces of vehicle information data
data interface	RJ485
work environment	-45℃～80℃,0～95%
Confidence	≥95%

Project Case

0.5-105km/H In Motion Axle Scale AC220V 50Hz Weigh In Motion Wim 0
