0.5~40km/H Low Speed Weigh In Motion Dynamic Tire Force Measuring
| Place of Origin | Zhenghou`China |
|---|---|
| Brand Name | Hengliang |
| Certification | ISO |
| Model Number | ZQS-40-SY |
| Minimum Order Quantity | 1 SET |
| Price | USD 20000-35000/SET |
| Packaging Details | Wooden box |
| Delivery Time | 5~7days |
| Payment Terms | T/T |
| Supply Ability | 30 SET/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Low Speed Weigh In Motion | Working Voltage | AC 110V~220V |
|---|---|---|---|
| Speed Rate | 0.5~40km/h | Axle Load | 40T (single Axle) |
| Single Axle Overload | 150% | Application | Dynamic Tire Force Measuring |
| Temperature Range | -45~+80℃ | Protection Level | IP68 |
| Highlight | 40km/H Low Speed Weigh In Motion,Dynamic Low Speed Weigh In Motion,40km/H weigh in motion systems |
||
Product Description
0.5~40km/H Low Speed Weigh In Motion Dynamic Tire Force Measuring
Product Function
in recent years, road transport vehicle overloading is a common phenomenon,.
it caused great harm to traffic safety and road bridge infrastructure. For another one, overloading vehicles load far more than roads and bridge designed to withstand loads,it will cause damage to pavement, and bridges broken, shorten life of road and bridge infrastructure and huge losses to state property.
Product Parameters
| Weighing error | 5%~10% |
| Single axle load | 40Ton |
| Max Single Load | 60Ton |
| Speed rate | 0.5~40km/h； |
| Speed error | ≤±1km/h |
| Wheelbase error | ≤±100mm |
| Power | AC 220V 50Hz |
| Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
| data interface | RJ485 |
| work environment | -45℃～80℃,0～95% |
| Confidence | ≥95% |
