Road studs are often used to enhance road markings, especially at night or in poor visibility conditions. By reflecting light, road studs can improve road visibility and help drivers clearly see key road information such as lane dividing lines, stop lines, intersection signs, etc., thereby increasing driving safety.
The application Scenario:
1. Crossroads or pedestrian zebra crossing waiting areas
The probability of traffic accidents occurring at intersections and pedestrian zebra crossing waiting areas is relatively high at night. Road studs serve to expand the nighttime road signs, enhancing nighttime traffic safety and visual comfort.
2. The edge of the curb or road dividing line on highways, sharp turns, etc.
The road curb and dividing line markings are located on one side of the road and are easily misjudged by the driver when driving at night, so road studs will be needed to assist the driver in making correct judgments.
Technical Parameters
| Items |
Description |
| Weight |
1.1 Kg |
| Dimension |
Diameter 150mm, height 50mm |
| Capacity |
<0.2W |
| Light Colors |
Red, Yellow, White, Green, Blue, Red+green+yellow, Red+green |
| Working Mode |
GPS sync flashing |
| Battery |
Continuous working for 72 hours after fully charged. |
| Shell |
Die cast aluminum alloy |
| Compressive performance |
30 Ton |
| Visibility |
>600 m |
| IP Class |
IP68 |
| Working Temperature |
-25℃～85℃ |
Mainl advantages:
- Improving road safety
Warning function: Road studs can emit warning lights at night or in dim light conditions, forming an obvious warning effect, reminding drivers to pay attention to the road conditions ahead and effectively reducing the occurrence of traffic accidents.
Separation function: Installing road stud on lane dividers or edge lines can clearly demarcate different lanes or road boundaries, helping drivers accurately determine vehicle positions and avoid crossing the line or deviating from the road.
- Strong durability
Excellent material: Road studs are made of high-strength, wear-resistant and corrosion-resistant materials, which can withstand the erosion of severe weather and traffic environment, ensuring long-term stable performance.
Firm installation: The road studs are tightly integrated with the road surface through a special installation method, and not easy to fall off or shift. They can maintain a stable warning effect even in harsh traffic conditions.
- Low maintenance cost
Easy to replace: Road studs are modular in design, making them easy to install and replace. When a stud is damaged or failed, only a single stud needs to be replaced, no need to carry out large-scale repairs of the entire road, which reduces maintenance costs.
Long service life: Using high-quality materials and advanced production technology, road studs usually have a long service life, reducing the need for frequent replacement and further reducing maintenance costs.
- Environmental protection and energy saving
Energy-saving effect: Solar road studs provide warning effects by reflecting the solar energy of vehicle lights, without consuming additional energy, which is in line with the environmental protection concept of energy conservation and emission reduction.
- Strong adaptability
Multiple specifications: Road studs come in various sizes and models to meet the needs of different road types, traffic flow, and climate conditions.
Customized service: Providing customized services, we can design and produce road stud products that meet specific requirements according to the specific needs of customers.
