Product Details
Place of Origin: Zhenghou`China
Brand Name: Hengliang
Certification: ISO
Model Number: ZQS-40-SY
Payment & Shipping Terms
Minimum Order Quantity: 1 SET
Price: USD 20000-35000/SET
Packaging Details: Wooden box
Delivery Time: 5~7days
Payment Terms: T/T
Supply Ability: 30 SET/Month
Type: |
Weight In Motion Station |
Single Axle: |
30T |
Maximum Overload: |
45T (single Axle) |
Speed: |
0.5~40km/h |
MTBF: |
≥20000h |
Weighing Accuracy: |
90%~97% |
Temperature Range: |
-45~+80℃ |
Protection Level: |
IP68 |
Type: |
Weight In Motion Station |
Single Axle: |
30T |
Maximum Overload: |
45T (single Axle) |
Speed: |
0.5~40km/h |
MTBF: |
≥20000h |
Weighing Accuracy: |
90%~97% |
Temperature Range: |
-45~+80℃ |
Protection Level: |
IP68 |
Axle Load 30T High Stability Low Speed Weight In Motion Station
vehicle passing the weighing area, the axle running on the quartz sensor and track detecting sensor paved in the lane, the signal generated by the quartz sensor collected, analyzed and processed by data collector, and sent to the weighing meter; the signal from the track detecting sensor , collected, processed and analyzed by the weighing meter, to acquire the driving track of vehicle.
Product Parameters
| Weighing error | 5%~10% |
| Single axle load | 40Ton |
| Max Single Load | 60Ton |
| Speed rate | 0.5~40km/h; |
| Speed error | ≤±1km/h |
| Wheelbase error | ≤±100mm |
| Power | AC 220V 50Hz |
| Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
| data interface | RJ485 |
| work environment | -45℃~80℃,0~95% |
| Confidence | ≥95% |
![]()
