1.Rapid construction, easy to install
Minimum slotted work amount on road, minimal structural damage to the road su***ce. Disposable casting by special rubber, hardening 2 to 3 hours, the road can be open to traffic the next day.
2.Superior applicability for particular lane
As for special lane, it is no need to reconstruct road, the quartz piezoelectric weighing sensor can be fully applicable to a wide angle longitudinal, transverse slope, sharp bends, and the lane or bridge not easy to be drained.
3.Effective dynamic testing, wider speed range
It with great rigidity, no deformation under load, with high frequency response, can accurately measure the rapidly changing dynamic loads.
The speed range of effective vehicle pass through is 0.5~105km/h, able to ensure the same weighing accuracy even when the speed change.
4.Wider range of temperature adaptation
Rinse temperature coefficient is only 0.02%, temperature changes little effect weighing accuracy, and no need calibration due to season and
temperature changes, can still ensure measurement accuracy in a variety of harsh environment, setting time and effort.Dynamic weighing
5.Dynamic weighing accurately and with stable performance
Great linearity and repeatability ensure accurate weighing stability, at the same time, the unique cutting technology and unique sensor structure
determines the insensitive from lateral force, therefore, even the vehicle brake, accelerate, change direction etc when passes through the sensor will not affect the accuracy of the system.
6.Small in size, easy to be hidden
Small in size, after the installation, it formed integrally with the road, so that the driver is difficult to accurately determine its location, and cannot
S bypass or do other cheating beh***ior.
7.No need drainage and maintenance
Use special rubber and pouring one time, embedded roadbed and form an integral whole with the road su***ce after installation. No need drainage, no need further daily maintenance in application.
8.Long life span
Excellent time stability, no aging phenomenon, no need or little need to calibration, not less than 10 years life span.
9.Great durability ability
Quartz sensor accept 5.400.000 times 50KN load change during durability test, it did not show any signs of damage.
